Additional Information
- ECC:
- Yes
- Execute Disable Bit:
- Yes
- Idle States:
- Yes
- Thermal Monitoring Technologies:
- Yes
- Market segment:
- Desktop
- Maximum number of PCI Express lanes:
- 20.0
- Supported instruction sets:
- AVX 2.0, SSE4.1, SSE4.2
- Scalability:
- 1S
- CPU configuration (max):
- 1.0
- Embedded options available:
- No
- Export Control Classification Number (ECCN):
- 5A992C
- Commodity Classification Automated Tracking System (CCATS):
- 740.17B1
- Use conditions:
- Workstation, PC/Client/Tablet
- PCI Express configurations:
- 1x16+1x4, 2x8+1x4
- Thermal solution specification:
- PCG 2020A
- Direct Media Interface (DMI) Revision:
- 4.0
- On-board graphics card:
- Yes
- Discrete graphics card:
- No
- Discrete graphics card model:
- Not available
- On-board graphics card model:
- Intel UHD Graphics 770
- On-board graphics card outputs supported:
- Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
- On-board graphics card base frequency:
- 300 MHz
- On-board graphics card dynamic frequency (max):
- 1600 MHz
- Number of displays supported (on-board graphics):
- 4.0
- On-board graphics card DirectX version:
- 12.0
- On-board graphics card OpenGL version:
- 4.5
- On-board graphics card maximum resolution (DisplayPort):
- 7680 x 4320 pixels
- On-board graphics card maximum resolution (eDP - Integrated Flat Panel):
- 5120 x 3200 pixels
- On-board graphics card maximum resolution (HDMI):
- 4096 x 2160 pixels
- On-board graphics card refresh rate at maximum resolution (DisplayPort):
- 60 Hz
- On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel):
- 120 Hz
- On-board graphics card refresh rate at maximum resolution (HDMI):
- 60 Hz
- On-board graphics card ID:
- 0xA780
- Number of execution units:
- 32.0
- Multi-Format Codec Engines:
- 2.0
- Harmonized System (HS) code:
- 8542310001
- Non-ECC:
- Yes
- Maximum internal memory:
- 192 GB
- Memory channels:
- Dual-channel
- Maximum internal memory supported by processor:
- 192 GB
- Memory types supported by processor:
- DDR4-SDRAM, DDR5-SDRAM
- Memory bandwidth (max):
- 89.6 GB/s
- Tjunction:
- 100 °C
- L2 cache:
- 28672 KB
- OpenCL version:
- 3.0
- PCI Express slots version:
- 4.0, 5.0
- Processor family:
- Intel® Core™ i7
- Processor manufacturer:
- Intel
- Processor model:
- i7-14700K
- Processor generation:
- Intel® Core™ i7 (14th gen)
- Processor cores:
- 20.0
- Processor threads:
- 28.0
- Processor boost frequency:
- 5.6 GHz
- Performance cores:
- 8.0
- Efficient cores:
- 12.0
- Performance-core base frequency:
- 3.4 GHz
- Efficient-core base frequency:
- 2.5 GHz
- Processor cache:
- 33 MB
- Processor cache type:
- Smart Cache
- Processor base power:
- 125 W
- Maximum turbo power:
- 253 W
- Processor socket:
- LGA 1700
- Package type:
- Box
- Cooler included:
- No
- Processor operating modes:
- 64-bit
- Memory bandwidth supported by processor (max):
- 89.6 GB/s
- Processor codename:
- Raptor Lake
- Processor ARK ID:
- 236783.0
- Efficient-core boost frequency:
- 4.3 GHz
- Performance-core boost frequency:
- 5.5 GHz
- Stepping:
- B0
- Maximum number of DMI lanes:
- 8.0
- Intel® Hyper Threading Technology (Intel® HT Technology):
- Yes
- Intel® Turbo Boost Technology:
- 2.0
- Intel® AES New Instructions (Intel® AES-NI):
- Yes
- Enhanced Intel SpeedStep Technology:
- Yes
- Intel VT-x with Extended Page Tables (EPT):
- Yes
- Intel® Secure Key:
- Yes
- Intel® OS Guard:
- Yes
- Intel 64:
- Yes
- Intel Virtualization Technology (VT-x):
- Yes
- Intel Virtualization Technology for Directed I/O (VT-d):
- Yes
- Intel® Speed Shift Technology:
- Yes
- Intel Turbo Boost Max Technology 3.0:
- Yes
- Intel® Volume Management Device (VMD):
- Yes
- Mode-based Execute Control (MBE):
- Yes
- Intel® Control-flow Enforcement Technology (CET):
- Yes
- Intel® Boot Guard:
- Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on CPU:
- Yes
- Intel® Quick Sync Video Technology:
- Yes
- Intel® Clear Video HD Technology (Intel® CVT HD):
- Yes
- Intel® Turbo Boost Max Technology 3.0 frequency:
- 5.6 GHz
- Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0:
- Yes
- Intel® Thread Director:
- Yes
- Intel® Standard Manageability (ISM):
- Yes
- Processor package size:
- 45 x 37.5 mm
- Graphics output:
- eDP 1.4b, DP 1.4a, HDMI 2.1
- Launch date:
- Q4'23
- Status:
- Launched
