Description
The Intel® E5-2609 v2 2.5 GHz Quad Core Processor enhances the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced SpeedStep® technology that allows tradeoffs to be made between performance and power consumption.
Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the E5-2609 v2 2.5 GHz Quad Core Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.
Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the E5-2609 v2 2.5 GHz Quad Core Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.
Additional Information
- Product type:
- Processor
- Component for:
- Server/workstation
- ECC:
- Yes
- Execute Disable Bit:
- Yes
- Idle States:
- Yes
- Thermal Monitoring Technologies:
- Yes
- Market segment:
- Server
- Maximum number of PCI Express lanes:
- 40.0
- Supported instruction sets:
- AVX
- Scalability:
- 2S
- CPU configuration (max):
- 2.0
- Embedded options available:
- Yes
- Physical Address Extension (PAE):
- 46 bit
- PCI Express CEM revision:
- 3.0
- Export Control Classification Number (ECCN):
- 5A992C
- Commodity Classification Automated Tracking System (CCATS):
- G077159
- On-board graphics card:
- No
- Discrete graphics card:
- No
- Discrete graphics card model:
- Not available
- On-board graphics card model:
- Not available
- Harmonized System (HS) code:
- 8542310001
- Maximum internal memory:
- 786432 MB
- Memory channels:
- Quad-channel
- Maximum internal memory supported by processor:
- 768 GB
- Memory types supported by processor:
- DDR3-SDRAM
- Memory clock speeds supported by processor:
- 800,1066,1333 MHz
- Tcase:
- 71 °C
- Intel® Virtualization Technology (Intel® VT):
- VT-d, VT-x
- Cache memory:
- 10 MB
- PCI Express slots version:
- 3.0
- Processor family:
- Intel® Xeon® E5 Family
- Processor manufacturer:
- Intel
- Processor model:
- E5-2609V2
- Processor cores:
- 4.0
- Processor threads:
- 4.0
- Processor boost frequency:
- 2.5 GHz
- Processor cache:
- 10240 KB
- Processor cache type:
- Smart Cache
- Processor socket:
- LGA 2011 (Socket R)
- Processor lithography:
- 22 nm
- Package type:
- Box
- Cooler included:
- Yes
- Processor base frequency:
- 2.5 GHz
- Processor operating modes:
- 64-bit
- Processor series:
- Intel Xeon E5-2600 v2
- System bus rate:
- 6.4 GT/s
- Thermal Design Power (TDP):
- 80 W
- VID Voltage Range:
- 0.65 - 1.3 V
- Bus type:
- QPI
- Number of QPI links:
- 2.0
- Memory bandwidth supported by processor (max):
- 42.6 GB/s
- Processor codename:
- Ivy Bridge EP
- Processor ARK ID:
- 75787.0
- Intel® Hyper Threading Technology (Intel® HT Technology):
- No
- Intel® Identity Protection Technology (Intel® IPT):
- No
- Intel® Turbo Boost Technology:
- No
- Intel Flex Memory Access:
- No
- Intel® AES New Instructions (Intel® AES-NI):
- Yes
- Enhanced Intel SpeedStep Technology:
- Yes
- Intel Trusted Execution Technology:
- Yes
- Intel® Transactional Synchronization Extensions:
- No
- Intel Enhanced Halt State:
- Yes
- Intel VT-x with Extended Page Tables (EPT):
- Yes
- Intel Demand Based Switching:
- Yes
- Intel® Secure Key:
- Yes
- Intel TSX-NI:
- No
- Intel® OS Guard:
- Yes
- Intel 64:
- Yes
- Intel Secure Key Technology version:
- 1.0
- Intel Virtualization Technology (VT-x):
- Yes
- Intel Virtualization Technology for Directed I/O (VT-d):
- Yes
- Conflict-Free processor:
- No
- Intel® vPro™ Platform Eligibility:
- Yes
- Supported memory types:
- DDR3-SDRAM
- Processor package size:
- 52.5mm x 45mm
- Born on date:
- Q3'13
- Bus bandwidth:
- 6.4
- Bus type units:
- GT/s
- Launch date:
- Q3'13
- Processor core voltage:
- 0.65–1.30
- Product name:
- Intel Xeon E5-2609 v2 (10M Cache, 2.50 GHz)
- Status:
- Launched
- Maximum memory:
- 768 GB
- Processor brand name:
- Intel Xeon v2
- Last change:
- 63903513.0
- Product family:
- Intel Xeon Processor E5 v2 Family
- Bus speed:
- 6.4 GT/s
