Description
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Additional Information
- Product type:
- Processor
- Component for:
- Server/workstation
- ECC:
- Yes
- Execute Disable Bit:
- Yes
- Market segment:
- Server
- Maximum number of PCI Express lanes:
- 48.0
- Supported instruction sets:
- SSE4.2, AVX, AVX 2.0, AVX-512
- Scalability:
- S4S
- Embedded options available:
- No
- PCI Express CEM revision:
- 3.0
- Export Control Classification Number (ECCN):
- 5A992C
- Commodity Classification Automated Tracking System (CCATS):
- G077159
- On-board graphics card:
- No
- Harmonized System (HS) code:
- 8542310001
- Maximum internal memory:
- 786432 MB
- Memory channels:
- Hexa-channel
- Maximum internal memory supported by processor:
- 768 GB
- Memory types supported by processor:
- DDR4-SDRAM
- Memory clock speeds supported by processor:
- 2666 MHz
- Tcase:
- 86 °C
- Package width:
- 43 mm
- Package depth:
- 137 mm
- Package height:
- 112 mm
- Package weight:
- 201 g
- PCI Express slots version:
- 3.0
- Processor family:
- Intel® Xeon® Gold
- Processor manufacturer:
- Intel
- Processor model:
- 6148
- Processor generation:
- 1st Generation Intel® Xeon® Scalable
- Processor cores:
- 20.0
- Processor threads:
- 40.0
- Processor boost frequency:
- 3.7 GHz
- Processor cache:
- 28160 KB
- Processor cache type:
- L3
- Processor socket:
- LGA 3647 (Socket P)
- Processor lithography:
- 14 nm
- Package type:
- Box, Tray
- Cooler included:
- No
- Processor base frequency:
- 2.4 GHz
- Processor operating modes:
- 64-bit
- Thermal Design Power (TDP):
- 150 W
- Processor codename:
- Skylake
- Processor ARK ID:
- 120489.0
- Processor code:
- SR3B6
- Stepping:
- H0
- Intel® Hyper Threading Technology (Intel® HT Technology):
- Yes
- Intel® Turbo Boost Technology:
- 2.0
- Intel® AES New Instructions (Intel® AES-NI):
- Yes
- Enhanced Intel SpeedStep Technology:
- Yes
- Intel Trusted Execution Technology:
- Yes
- Intel® Transactional Synchronization Extensions:
- Yes
- Intel VT-x with Extended Page Tables (EPT):
- Yes
- Intel TSX-NI:
- Yes
- Intel 64:
- Yes
- Intel Virtualization Technology (VT-x):
- Yes
- Intel Virtualization Technology for Directed I/O (VT-d):
- Yes
- Intel TSX-NI version:
- 1.0
- Conflict-Free processor:
- Yes
- Intel® vPro™ Platform Eligibility:
- Yes
- Intel® Speed Shift Technology:
- Yes
- Intel Turbo Boost Max Technology 3.0:
- No
- Intel® Optane™ Memory Ready:
- No
- AVX-512 Fused Multiply-Add (FMA) units:
- 2.0
- Intel® Volume Management Device (VMD):
- Yes
- Intel® Run Sure Technology:
- Yes
- Mode-based Execute Control (MBE):
- Yes
- Supported memory types:
- DDR4-SDRAM
- Processor package size:
- 76mm x 56.5mm
- Launch date:
- Q3'17
- Status:
- Launched
- Maximum memory:
- 768 GB
- Processor brand name:
- Intel Xeon Gold\nIntel Xeon Gold Processor
- Last change:
- 63903513.0
- Product family:
- Intel Xeon Processors
- Intel® Speed Shift Technology version:
- 1.0
- Intel® Run Sure Technology version:
- 1.0
- Intel® Volume Management Device (VMD) version:
- 1.0
- Memory speed (max):
- 2666 MHz
- Mode-based Execute Control (MBE) version:
- 1.0
- Number of UPI links:
- 3.0
