Lightweight powerhouse
With a starting weight of less than one kilogram, the ThinkPad X1 Nano laptop is our lightest ThinkPad ever. Yet it’s a heavyweight performer. Packed with 11th Gen Intel® vPro® power, this 13" laptop features a choice of Windows 10 or Linux operating systems. It also boasts productivity-rich features like always-on responsiveness, optional 5G functionality, speedy Thunderbolt™ 4, Rapid Charge, and a 16:10 aspect ratio for more screen.
With a starting weight of less than one kilogram, the ThinkPad X1 Nano laptop is our lightest ThinkPad ever. Yet it’s a heavyweight performer. Packed with 11th Gen Intel® vPro® power, this 13" laptop features a choice of Windows 10 or Linux operating systems. It also boasts productivity-rich features like always-on responsiveness, optional 5G functionality, speedy Thunderbolt™ 4, Rapid Charge, and a 16:10 aspect ratio for more screen.
- Number of built-in speakers:
- 4.0
- Built-in microphone:
- Yes
- Number of microphones:
- 4.0
- Audio system:
- Dolby Atmos
- Battery capacity:
- 48 Wh
- Battery technology:
- Lithium Polymer (LiPo)
- Fast charging:
- Yes
- Battery life (max):
- 13.6 h
- Front camera:
- Yes
- Infrared (IR) camera:
- Yes
- Front camera resolution:
- 1280 x 720 pixels
- Front camera HD type:
- HD
- Privacy camera:
- Yes
- Privacy type:
- Privacy shutter
- Compliance certificates:
- RoHS
- Operating system installed:
- Windows 11 Pro
- Product colour:
- Black
- Product type:
- Laptop
- Colour name:
- Black Paint
- Housing material:
- Carbon fibre, Magnesium
- Display diagonal:
- 33 cm (13)"
- Display resolution:
- 2160 x 1350 pixels
- HD type:
- 2K Ultra HD
- Touchscreen:
- No
- Panel type:
- IPS
- Anti-glare screen:
- Yes
- Display brightness:
- 450 cd/m²
- LED backlight:
- Yes
- Native aspect ratio:
- 16:10
- Internal memory:
- 16 GB
- Internal memory type:
- LPDDR4x-SDRAM
- Memory form factor:
- On-board
- Memory clock speed:
- 4266 MHz
- Form factor:
- Clamshell
- Certification:
- ENERGY STAR,EPEAT Gold,RoHS,TCO
- Idle States:
- Yes
- CPU configuration (max):
- 1.0
- Embedded options available:
- No
- Trusted Platform Module (TPM):
- Yes
- Trusted Platform Module (TPM) version:
- 2.0
- On-board graphics card:
- Yes
- Discrete graphics card:
- No
- Discrete graphics card model:
- Not available
- On-board graphics card model:
- Intel Iris Xe Graphics
- On-board GPU manufacturer:
- Intel
- On-board graphics card family:
- Intel Iris Xe Graphics
- Pointing device:
- ThinkPad UltraNav
- Numeric keypad:
- No
- Keyboard backlit:
- Yes
- Spill-resistant keyboard:
- Yes
- Keyboard language:
- English
- Harmonized System (HS) code:
- 84713000
- Maximum internal memory:
- 16 GB
- Memory channels:
- Dual-channel
- Mobile network connection:
- No
- Top Wi-Fi standard:
- Wi-Fi 6 (802.11ax)
- Antenna type:
- 2x2
- WLAN controller model:
- Intel Wi-Fi 6 AX201
- WLAN controller manufacturer:
- Intel
- Near Field Communication (NFC):
- No
- Operating temperature (T-T):
- 5 - 35 °C
- Storage temperature (T-T):
- 5 - 43 °C
- Operating relative humidity (H-H):
- 8 - 95%
- Storage relative humidity (H-H):
- 5 - 95%
- Bluetooth:
- Yes
- Bluetooth version:
- 5.2
- Audio chip:
- Realtek ALC3306
- Ethernet LAN:
- No
- Wi-Fi standards:
- Wi-Fi 6 (802.11ax)
- Combo headphone/mic port:
- Yes
- USB Type-C DisplayPort Alternate Mode:
- Yes
- Thunderbolt 4 ports quantity:
- 2.0
- Intel® Thunderbolt 4:
- Yes
- AC adapter power:
- 65 W
- USB Power Delivery (USB PD):
- Yes
- Processor family:
- Intel® Core™ i5
- Processor manufacturer:
- Intel
- Processor model:
- i5-1130G7
- Processor generation:
- 11th gen Intel® Core™ i5
- Processor cores:
- 4.0
- Processor boost frequency:
- 4 GHz
- Processor cache:
- 8 MB
- Processor frequency:
- 1.8 GHz
- Motherboard chipset:
- Intel SoC
- Configurable TDP-down:
- 7 W
- Configurable TDP-down frequency:
- 0.8 GHz
- Configurable TDP-up frequency:
- 1.8 GHz
- Configurable TDP-up:
- 15 W
- Intel Trusted Execution Technology:
- No
- Intel VT-x with Extended Page Tables (EPT):
- Yes
- Intel Virtualization Technology (VT-x):
- Yes
- Intel Virtualization Technology for Directed I/O (VT-d):
- Yes
- Intel Stable Image Platform Program (SIPP):
- No
- Intel Software Guard Extensions (Intel SGX):
- No
- Fingerprint reader:
- Yes
- Password protection:
- Yes
- Password protection type:
- HDD, Power on, Supervisor
- Smart card reader:
- No
- Windows Hello:
- Yes
- Operating system architecture:
- 64-bit
- Operating system language:
- English
- Total storage capacity:
- 256 GB
- Storage media:
- SSD
- Optical drive type:
- No
- Total SSDs capacity:
- 256 GB
- Number of SSDs installed:
- 1.0
- SSD capacity:
- 256 GB
- SSD interface:
- NVMe, PCI Express 3.0
- NVMe:
- Yes
- SSD form factor:
- M.2
- Card reader integrated:
- No
- Sustainability certificates:
- ENERGY STAR, EPEAT Gold, TCO
- Width:
- 292.8 mm
- Weight:
- 907 g
- Depth:
- 207.7 mm
- Height (front):
- 1.39 cm
- Height (rear):
- 1.67 cm
