Overview
Key Features
- Business Mini PC Black 90 W
- Intel Core Ultra 7 265T Processor cores: 20
- 16 GB DDR5-SDRAM 1 x 16 GB
- 512 GB SSD
- Intel® Graphics
- Ethernet LAN 10,100,1000 Mbit/s Wi-Fi 6E (802.11ax) Bluetooth
- Windows 11 Pro 64-bit
Specifications
| Dimensions Weight | |
|---|---|
| Width | 36 mm |
| Height | 182 mm |
| Depth | 178 mm |
| Weight | 1160 g |
| Build Materials Chassis Design | |
| Chassis type | Micro PC |
| Antenna | |
| Antenna design | Internal |
| Antenna type | 2x2 |
| Audio | |
| Audio chip | Realtek ALC3204 |
| Audio system | High Definition Audio |
| Battery | |
| Product colour | Black |
| Camera | |
| Operating system installed | Windows 11 Pro |
| Carbon footprint | |
| Total carbon footprint (kg of CO2e) | 77.6 |
| Computer case | |
| Power supply | 90 |
| USB 2.0 ports quantity | 2 |
| Computer system | |
| Internal memory | 16 |
| Maximum internal memory | 64 |
| Processor cache | 30 |
| Processor cores | 20 |
| Processor family | Intel Core Ultra 7 |
| Processor generation | Intel Core Ultra (Series 2) |
| Processor manufacturer | Intel |
| Processor model | 265T |
| Data transmission | |
| Bluetooth | Yes |
| Design | |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Market positioning | Business |
| Operating relative humidity (H-H) | 20 - 80 |
| Operating temperature (T-T) | 10 - 35 |
| Product type | Mini PC (<= 3L) |
| Storage relative humidity (H-H) | 5 - 95 |
| Storage temperature (T-T) | -40 - 65 |
| Display | |
| On-board graphics card model | Intel® Graphics |
| Docking station | |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Ethernet LAN features | |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Features | |
| Box contents | internal antenna |
| Carbon emissions, end-of-life (kg of CO2e) | 0.54 |
| Carbon emissions, energy usage (kg of CO2e) | 33.45 |
| Carbon emissions, logistics (kg of CO2e) | 2.17 |
| Carbon emissions, manufacturing (kg of CO2e) | 41.52 |
| Discrete graphics card model | Not available |
| DisplayPort version | 1.4a |
| DisplayPorts quantity | 1 |
| Internal memory type | DDR5-SDRAM |
| Memory data transfer rate | 5600 |
| Memory slots | 2x SO-DIMM |
| Motherboard chipset | Intel Q870 |
| Non-ECC | Yes |
| Number of SSDs installed | 1 |
| Number of storage drives installed | 1 |
| NVMe | Yes |
| On-board graphics card | Yes |
| On-board graphics card family | Intel® Graphics |
| Processor boost frequency | 5.3 |
| Processor cache type | Smart Cache |
| Processor threads | 20 |
| SSD capacity | 512 |
| SSD form factor | M.2 |
| SSD interface | PCI Express 4.0 |
| Storage media | SSD |
| Total storage capacity | 512 |
| Trusted Platform Module (TPM) | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax) |
| Graphics | |
| Discrete graphics card | No |
| On-board GPU manufacturer | Intel |
| Network | |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Neural processor unit (NPU) | |
| AI software frameworks supported by NPU | DirectML, ONNX RT, OpenVINO, WebNN, Windows ML |
| GPU performance up to | 8 |
| Neural processor unit (NPU) | Intel AI Boost |
| NPU performance up to | 13 |
| Total processor performance up to | 33 |
| Performance | |
| Efficient cores | 12 |
| Performance cores | 8 |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Processor | |
| Efficient-core base frequency | 1.2 |
| Efficient-core Max Turbo Frequency | 4.6 |
| Performance-core base frequency | 1.5 |
| Performance-core Max Turbo Frequency | 5.2 |
| Storage | |
| Total SSDs capacity | 512 |
From the manufacturer
Rich content supplied by Dell via 1WorldSyncSpecifications
Display
- On-board graphics card model
- Intelgraphics
Processor
- Efficient-core base frequency
- 1.2 GHz
- Efficient-core Max Turbo Frequency
- 4.6 GHz
- Performance-core base frequency
- 1.5 GHz
- Performance-core Max Turbo Frequency
- 5.2 GHz
Performance
- Efficient cores
- 12
- Performance cores
- 8
Neural processor unit (NPU)
- AI software frameworks supported by NPU
- Directml, Onnxrt, Openvino, Webnn, Windowsml
- GPU performance up to
- 8
- Neural processor unit (NPU)
- Intelaiboost
- NPU performance up to
- 13 TOPS
- Total processor performance up to
- 33 TOPS
Storage
- Total SSDs capacity
- 512 GB
Graphics
- Discrete graphics card
- No
- On-board GPU manufacturer
- Intel
Audio
- Audio chip
- Realtekalc3204
- Audio system
- High Definition Audio
Data transmission
- Bluetooth
- Yes
Network
- WLAN controller model
- Intelwi Fi6eax211
Antenna
- Antenna design
- Internal
- Antenna type
- 2x2
Ports & interfaces
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 1
Docking station
- HDMI ports quantity
- 1
- HDMI version
- 2 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 3
Software
- Operating system installed
- Windows11pro
Computer system
- Internal memory
- 16 GB
- Maximum internal memory
- 64 GB
- Processor cache
- 30 MB
- Processor cores
- 20
- Processor family
- Intelcoreultra7
- Processor generation
- Intelcoreultra Series2
- Processor manufacturer
- Intel
- Processor model
- 265t
Features
- Box contents
- internal antenna
- Carbon emissions, end-of-life (kg of CO2e)
- 0.54
- Carbon emissions, energy usage (kg of CO2e)
- 33.45
- Carbon emissions, logistics (kg of CO2e)
- 2.17
- Carbon emissions, manufacturing (kg of CO2e)
- 41.52
- Discrete graphics card model
- Not available
- DisplayPort version
- 1 4a
- DisplayPorts quantity
- 1
- Internal memory type
- DDR5-SDRAM
- Memory data transfer rate
- 5600
- Memory slots
- 2x SO-DIMM
- Motherboard chipset
- Intel Q870
- Non-ECC
- Yes
- Number of SSDs installed
- 1
- Number of storage drives installed
- 1
- NVMe
- Yes
- On-board graphics card
- Yes
- On-board graphics card family
- Intelgraphics
- Processor boost frequency
- 5.3 GHz
- Processor cache type
- Smartcache
- Processor threads
- 20
- SSD capacity
- 512 GB
- SSD form factor
- M 2
- SSD interface
- Pciexpress4 0
- Storage media
- Ssd
- Total storage capacity
- 512 GB
- Trusted Platform Module (TPM)
- Yes
- Wi-Fi
- Yes
- Wi-Fi standards
- 802 11a, 802 11b, 802 11g, Wi Fi4 802 11n, Wi Fi5 802 11ac, Wi Fi6e 802 11ax
Design
- Product colour
- Black
- Cable lock slot
- Yes
- Cable lock slot type
- Kensington
- Ethernet LAN
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Market positioning
- Business
- Operating relative humidity (H-H)
- 20 - 80
- Operating temperature (T-T)
- 10 - 35
- Product type
- Mini PC (<= 3L)
- Storage relative humidity (H-H)
- 5 - 95
- Storage temperature (T-T)
- -40 - 65
Build Materials Chassis Design
- Chassis type
- Micropc
Dimensions Weight
- Width
- 36 mm
- Height
- 182 mm
- Depth
- 178 mm
- Weight
- 1160 g
Computer case
- Power supply
- 90
- USB 2.0 ports quantity
- 2
Ethernet LAN features
- Cabling technology
- 10 100 1000base T X
- Ethernet LAN data rates
- 10, 100, 1000
