Overview
Intelligent Roaming Technologies, Full Wi-Fi Coverage
Intelligent roaming with 802.11k/v/r protocols, enabling clients to seamlessly access APs with stronger signals,
and achieving low roaming delay and zero stalling during roaming.
PoE and DC Power Supply, Flexible Deployment
With PoE in, a single network cable can transmit both data and power without external power supply.
With a 48V DC power supply, there's no need for PoE switches, reducing networking costs.
Intelligent roaming with 802.11k/v/r protocols, enabling clients to seamlessly access APs with stronger signals,
and achieving low roaming delay and zero stalling during roaming.
PoE and DC Power Supply, Flexible Deployment
With PoE in, a single network cable can transmit both data and power without external power supply.
With a 48V DC power supply, there's no need for PoE switches, reducing networking costs.
Key Features
- 2.4 GHz 574 Mbit/s
- 5 GHz 1201 Mbit/s
- Maximum data transfer rate: 1775 Mbit/s
- IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af
- WPA-Enterprise, WPA-Personal, WPA2, WPA2-Enterprise, WPA2-Personal, WPA3, WPA3-Enterprise, WPA3-Personal
- Power over Ethernet (PoE)
- Antennas quantity: 2 Internal
Specifications
| Dimensions Weight | |
|---|---|
| Width | 220 mm |
| Height | 49 mm |
| Depth | 220 mm |
| Weight | 600 g |
| Antenna | |
| Antenna direction type | Omni-directional |
| Antenna type | Internal |
| Battery | |
| Product colour | White |
| Data transmission | |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
| Maximum data transfer rate | 1775 |
| Design | |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN features | |
| DHCP client | Yes |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Features | |
| 5 GHz | Yes |
| 6 GHz | No |
| IPv4 & IPv6 features | Icmpv6, IPv6 ping |
| Maximum data transfer rate (5 GHz) | 1201 |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Mounting kit | Yes |
| Package depth | 319 |
| Package height | 278 |
| Package weight | 1040 |
| Package width | 507 |
| Power over Ethernet (PoE) | Yes |
| Security algorithms | WPA2, WPA2-Enterprise, Wpa2 Personal, WPA3, WPA3-Enterprise, WPA3-Personal, WPA-Enterprise, Wpa Personal |
| Network | |
| Networking standards | IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af |
From the manufacturer
Rich content supplied by Ruijie Networks via 1WorldSyncSpecifications
Data transmission
- Bluetooth
- Yes
- Bluetooth version
- 5 1
- Maximum data transfer rate
- 1775
Network
- Networking standards
- Ieee802 11ax, Ieee802 11b, Ieee802 11g, Ieee802 11n, Ieee802 3af
Antenna
- Antenna direction type
- Omni Directional
- Antenna type
- Internal
Features
- Height
- 49 mm
- Depth
- 220 mm
- 5 GHz
- Yes
- 6 GHz
- No
- IPv4 & IPv6 features
- Icmpv6, Ipv6ping
- Maximum data transfer rate (5 GHz)
- 1201
- MIMO
- Yes
- MIMO type
- Multiusermimo
- Mounting kit
- Yes
- Package depth
- 319
- Package height
- 278
- Package weight
- 1040
- Package width
- 507
- Power over Ethernet (PoE)
- Yes
- Security algorithms
- Wpa2, Wpa2 Enterprise, Wpa2 Personal, Wpa3, Wpa3 Enterprise, Wpa3 Personal, Wpa Enterprise, Wpa Personal
Design
- Product colour
- White
- Cable lock slot
- Yes
- Cable lock slot type
- Kensington
- Ethernet LAN (RJ-45) ports
- 1
Dimensions Weight
- Width
- 220 mm
- Weight
- 600 g
Ethernet LAN features
- DHCP client
- Yes
- Ethernet LAN data rates
- 10, 100, 1000
