Rock-solid in Harsh Environments
Adopts completely sealed, waterproof, dustproof, moisture proof and flame-retardant, wind erosion protection,
Wide Temperature range, and 4kV surge protection design.
Omni-directional Coverage with Long Range
Built-in 4 high gain antennas, supports full coverage with radius of 100 meters at 2.4GHz, and 300 meters at 5GHz*.
Easy Installation, Firmly Fixed
Rack-separated mounting design, easily installation on high. Replace plastic cable ties by iron hoop.
Adopts completely sealed, waterproof, dustproof, moisture proof and flame-retardant, wind erosion protection,
Wide Temperature range, and 4kV surge protection design.
Omni-directional Coverage with Long Range
Built-in 4 high gain antennas, supports full coverage with radius of 100 meters at 2.4GHz, and 300 meters at 5GHz*.
Easy Installation, Firmly Fixed
Rack-separated mounting design, easily installation on high. Replace plastic cable ties by iron hoop.
Key Features
- 2.4 GHz 574 Mbit/s
- 5 GHz 1201 Mbit/s
- Maximum data transfer rate: 1775 Mbit/s
- IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
- WPA-PSK, WPA2-PSK
- Power over Ethernet (PoE)
- Antennas quantity: 4 Internal
Specifications
| Dimensions Weight | |
|---|---|
| Width | 200 mm |
| Height | 166 mm |
| Depth | 220 mm |
| Weight | 1200 g |
| Antenna | |
| Antenna direction type | Omni-directional |
| Antenna type | Internal |
| Battery | |
| Product colour | White |
| Computer system | |
| Internal memory | 256 |
| Data transmission | |
| Maximum data transfer rate | 1775 |
| Design | |
| Ethernet LAN (RJ-45) ports | 2 |
| LED indicators | Yes |
| Operating relative humidity (H-H) | 0 - 100 |
| Storage relative humidity (H-H) | 0 - 100 |
| Ethernet LAN features | |
| DHCP client | Yes |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Features | |
| 5 GHz | Yes |
| 6 GHz | No |
| Depth | 220 |
| Flash memory | 16 |
| Height | 166 |
| Maximum data transfer rate (5 GHz) | 1201 |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Number of users | 100 |
| Power over Ethernet (PoE) | Yes |
| Security algorithms | WPA2-PSK, WPA-PSK |
| Warranty period | 3 |
| Network | |
| Networking standards | IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at |
| Security | |
| Service Set Identifier (SSID) features | Hiddenssid |
